| Electrical Specifications | |
| FreqRange | 2400-2500/5150-5850MHz |
| Gain | 6/8±0.5dBi |
| Horizontal Beamwidth | 360 º |
| Vertical Beamwidth | 70±5º |
| VSWR | ≤2.0 |
| ovality | ≤2dB |
| Impedance | 50 Ω |
| Polarization | vertical |
| Max. Power | 50W |
| Lightning Protection | DC ground |
| Connector | N-J |
| Mechanical Specifications | |
| mm(Dimension) | ¢20*350 mm |
| kg(Weight0) | 0.2kg |
| ( material) | copper |
| (Radome Color) | gray |
| (Operational Humidity) | < 95% |
| (Rated Wind Velocity) | 36.9 m/s |
| (Radome material) | Fiberglass |
| (Operating temperaturec) | -40~55 º |
