Elevator parts uni-directional and bi-directional speed governor


Elevator Parts Uni-Directional and Bi-Directional Speed Governor

Specification
Over speed governor used together with tension device.
Unidirectional for MR; Bi-directional for MR;
Unidirectional for MRL;Bi-directional for MRL.



We have different kinds of speed governor as below :

Product NameDescription
Bi-directional Overspeed GovernorModelNV52-240F
Rated Speed<=2.5m/s
Wire Rope Diameter(mm)Φ6, Φ8
Sheave Diameter(mm)Φ240mm
Tension Force>=1000N
Overspeed Switch VoltageAC220V
Bi-directional Overspeed GovernorModelNV52-240B
Rated Speed<=2.5m/s
Wire Rope Diameter(mm)Φ6, Φ8
Sheave Diameter(mm)Φ240mm
Tension Force>=1000N
Overspeed Switch VoltageAC220V
Bi-directional Overspeed Governor for MRLModelNV52-240E
Rated Speed<=0.63m/s
Wire Rope Diameter(mm)Φ6, Φ8
Sheave Diameter(mm)Φ240mm
Tension Force>=1000N
Overspeed Switch VoltageAC220V/DC24V
Switch Electromagnetic VoltageAC220V/DC24V
Action Electromagnetic VoltageAC220V/DC24V
Uni-directional Overspeed Governor for MRLModelNV52-240A
Rated Speed<=1.75m/s
Wire Rope Diameter(mm)Φ6, Φ8
Sheave Diameter(mm)Φ240mm
Tension Force>=1000N
Overspeed Switch VoltageAC220V/DC24V
Switch Electromagnetic VoltageAC220V/DC24V
Action Electromagnetic VoltageAC220V/DC24V
Bi-directional Overspeed Governor for MRLModelNV52-187
Rated Speed<=1.75m/s
Wire Rope Diameter(mm)Φ6, Φ8
Sheave Diameter(mm)Φ240mm
Tension Force>=500N
Overspeed Switch VoltageAC220V/DC24V
Switch Electromagnetic VoltageAC220V/DC24V
Action Electromagnetic VoltageAC220V/DC24V
Bi-directional Overspeed Governor for MRL Home ElevatorModelNV52-186
Rated Speed<=0.63m/s
Wire Rope Diameter(mm)Φ6
Sheave Diameter(mm)Φ200mm
Tension Force>=500N
Overspeed Switch VoltageAC220V/DC24V
Switch Electromagnetic VoltageAC220V/DC24V
Action Electromagnetic VoltageAC220V/DC24V
Uni-directional Overspeed GovernorModelNV52-240
Rated Speed<=2.5m/s
Wire Rope Diameter(mm)Φ6, Φ8
Sheave Diameter(mm)Φ240mm
Tension Force>=1000N
Overspeed Switch VoltageAC220V/DC24V



Elevator Parts Uni-Directional and Bi-Directional Speed Governor



Elevator Parts Uni-Directional and Bi-Directional Speed Governor

·Shaft Components includes
Machined /Cold Drawn/ Hollow Guide Rail, Fishplate, Fasteners, Anchor Bolt, Rail Rracket etc.
·Elevator Cabin includes
Complete Elevaotr Cabin, Car Frame, Counterweight Frame and Counterweight Block,Guide Shoes, Rope Attachment etc.
·Door System includes
Mitsubishi, Fermator and Selcom Door Operator and Landing Door, Door Panel, Door Spare Parts,Safety Light Curtain/Photocell etc.
·Safetey Components includes
Safety Gear, Speed Governor, Rope Brake, Oil Buffer and Rubber Buffer etc.
·Traction System includes
Geared/Gearless Traction Machine, Pulley Sheave,Anti-Vibration Pad,Steel Wire Rope etc.
·Electrical Components inclueds
Integrated and Separated Controlling Cabinet,Yaskawa L1000A Inverter, Elevator Display,COP&LOP&HOP, Elevator Button, Flat Traveling Cable etc.


Elevator Parts Uni-Directional and Bi-Directional Speed Governor

Elevator Parts Uni-Directional and Bi-Directional Speed Governor
