|Case Material||SS304 stainless steel,tempered glass,acrylic|
|Pass width||1200mm(<1200mm can be customized)|
|Mechanism||DC 24V Brushless motor|
|Movement structure||Secondary reduction movement|
|Passage direction||Single directional / Bi-directional|
|Opening method||ID / IC card reader, infrared sensor, exit button, etc.|
|Communication interface||Dry contact|
|Protection function||electromechanical anti-collision, infrared anti-pinch, illegal intrusion infrared alarm|
|Infrared sensor||4 pairs|
1,Fault self-check and alarm prompt function, convenient for users to maintain and use;
2,Through the built-in small button on the main control board, the running status of the device can be programmed;
3,Mechanical structure, induction double anti-pinch function, when the swing arm is in the process of resetting, it will automatically stop or the motor will stop working within the default time, and reset again after the default delay (until reset), and the force is very small ( ≤2Kg);
4,Sound and light alarm function: including illegal entry and trailing alarm;
5,Anti-shock function, the swing arm is automatically locked when it does not receive the opening signal;
6,Swing lever (arm) synchronization function;
7,Automatic reset function. After opening the gate, if there is no pass within the specified time, the system will automatically cancel the user's permission to pass this time. The standard is automatic reset 5 seconds after opening;
8,The channel automatically opens after power off, and automatically closes after power on;
9,It can be connected to a variety of card readers, and can receive relay switch signals to work;
10,One-way or two-way control of personnel entry and exit;
11, Remote control and management can be realized directly through the management computer;
Shenzhen Zenidea Intelligent Technology Co., Ltd, a high-tech enterprise with 13 years experience specializing in the production of turnstiles and smart parking system. It is an enterprise integrating production, research and development, and sales. Obtained 30+ patent certificates. In the product production process, the product needs to go through 320 production processes, 12 quality inspection processes, and 72-hour aging process. In terms of software, we continue to optimize and upgrade standardized products and special customization requirements based on market application requirements and customer experience. We always insist on continuously innovating technology, and strive to create a global security industry boutique, to provide customers with better products.
Our production range includes tripod turnstiles, swing barrier gates, speed gates ,full height turnstiles, parking boom barrier and revolving doors which are widely used in subways, office building and other public area
> 7000m³ manufacturing center located in Shenzhen,China
> 9 R&D centers across China to provide timely and effective technical support
> 13 years of R & D and production experience
> 30+ Patents and various other related certificates (CE,RoHS,ISO9001,CNAS,IAF)
> Top 10 Security Brands in China
> Appraised as a high-tech enterprise six consecutive years
> 20+ footprint,products sold to 20+ countries
1.How about your company's actual strength?
7000m3 manufacturing center located in Shenzhen,China
9 R&D centers across China to provide timely and effective technical support
13 years of R & D and production experience
30+ Patents and various other related certificates (CE,RoHS,ISO9001,CNAS,IAF)
Top 10 Security Brands in China
2.How do you do after-sale service?
Free lifetime technical support(video / picture / remote assistance)
24/7 technical online service
Free replacement of hardware damaged during the warranty period (except for human factors).
3.How about your package?
Seaworthy wooden case + Foam.
Wooden case package of Export exempted from inspection plus pearl wool and plastic wrap.
4.How about the lead time?
Stock products: 5-7 days
Out-of-stock products: According to the production schedule,12-20 days.
5.How about the payment method?
T/T , Western Union, PayPal...
